Hikvision DS-7116HGHI-M1(STD)
16-ch
720p Mini 1U H.265 DVR
Deep learning based human and vehicle targets classification of Motion
Detection 2.0
H.265 Pro+/H.265 Pro/H.265 video compression HDTVI/AHD/CVI/CVBS/IP video
input
Audio via coaxial cable
Up to 18-ch IP camera input (up to 5 MP) Encoding ability up to 1080p lite
@ 15 fps Max. 1200 m for 720p HDTVI signal
Available on backorder
Pick up from the Woodmart Store
To pick up today
Free
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
DHL Courier delivery
DHL courier will deliver to the specified address
1-3 Days
Free
Warranty 1 year
Free 30-Day returns
Payment Methods:
Description
Hikvision DS-7116HGHI-M1(STD) 16-Channel Turbo HD DVR
Powerful & Reliable DVR for Medium to Large CCTV Systems
The Hikvision DS-7116HGHI-M1 is a high-capacity 16-channel DVR designed for professional surveillance systems, offering efficient video compression, smart detection features, and flexible camera compatibility.
🔹 Key Features
✔️ 16 Analog Channels (HDTVI / AHD / HDCVI / CVBS)
✔️ Supports up to 18 IP cameras (up to 5MP)
✔️ H.265 Pro+ / H.265 / H.264+ compression for optimized storage
✔️ Recording up to 1080p Lite resolution
✔️ Motion Detection 2.0 with human & vehicle classification (AI-based)
✔️ HDMI & VGA simultaneous output (Full HD)
✔️ Audio over coaxial cable support
🔹 Performance & Recording
- Incoming Bandwidth: up to 96 Mbps
- Synchronous playback for 16 channels
- Smart search by event (human/vehicle detection)
- Dual-stream technology for efficient remote viewing
🔹 Storage & Connectivity
- 1 SATA interface (supports up to 10TB HDD)
- 2 × USB 2.0 ports
- 1 × RJ45 (10/100 Mbps network port)
- Remote access via Hik-Connect app & PC software
🔹 Ideal Applications
Medium to large CCTV systems
Offices and companies
Shops and commercial spaces
Schools, clinics, and warehouses
Why Choose This DVR?
✔️ Supports multiple camera technologies (5-in-1)
✔️ AI-based motion detection reduces false alarms
✔️ Efficient storage with H.265+ compression
✔️ Reliable 24/7 performance
Perfect For
If you need a scalable and reliable 16-channel DVR, this model is perfect for expanding surveillance systems with smart detection and flexible camera support.
